| Ref. Standard | ANSI/TIA 568.2-D, ISO/IEC 11801, YD-T1019, UL444 |
|---|
| Typical Structure Parameters | ||||||
|---|---|---|---|---|---|---|
| Conductor Material | Conductor Diameter | Insulating Material | Insulator Diameter | Sheath Material | Outside Dia. | Color |
| Oxygen-Free Copper | 23AWG | HDPE | 1.05±0.05 | PVC or LSZH | 7.60 mm | Optional |
| Mechanical and Electrical Performance | |
|---|---|
| Conductor Dc Resistance | 73.2 Ω/km |
| Dielectric Strength Between Conductors | 1.5KV ac for a minimum of 2s, without breakdown |
| Dc Resistance Unbalance Inside The Pairs | ≤4% |
| Mutual Capacitance | ≤5.6nF/100m |
| Application Scenario | Description & Compliance |
|---|---|
| High-Speed Unshielded 10G LAN | The ultimate unshielded solution for enterprise offices and commercial premises requiring 10Gbps speed without complex grounding requirements. Ideal for environments free from severe electromagnetic noise. |
| Horizontal Workspace Pipelines | Perfectly optimized for standard 90-meter indoor horizontal distribution pathways, providing full-throttle network delivery straight from telecommunications rooms to workstation terminals. |
| Ultra-Wide 500MHz Data Pipelines | Supports a massive 500MHz bandwidth capacity, maintaining an advanced 10Gbps typical application rate to effortlessly manage high-density cloud computing, server virtualization, and massive file transfers. |
| Crosstalk-Suppressed Internals | Employs an integrated center cross PE skeleton framework to isolate the four twisted pairs structurally, vastly improving internal electrical stability and reducing near-end crosstalk (NEXT). |
| Premium Copper Specifications | Constructed with high-quality 23AWG solid Oxygen-Free Copper (OFC) cores, guaranteeing exceptionally low loop DC resistance ($\le 73.2\ \Omega/\text{km}$) that reaches and greatly exceeds standard Cat6A metrics. |
| Eco-Safety Public Infrastructure | Available in optional flame-retardant LSZH (Low Smoke Zero Halogen) or standard PVC outer sleeves to easily pass modern commercial environmental safety and toxic smoke codes. |
| Global Network Compliances | Fully complies with mainstream global structured data cabling installation parameters, including ANSI/TIA 568.2-D, ISO/IEC 11801, YD-T1019, and UL444 standard benchmarks. |
| Instructions | |||
|---|---|---|---|
| Operating Temperature | -10~60°C | Construction Temperature | 0~40°C |
| Recommended Bending Radius for Laying | ≥8 * OD | Recommended to Lay Tension | ≤110N (Short-term) ≤20N (Long-term) |
| Packing | Optional, According to Customer Requirements to Discuss. |
|---|
No documents available for this product.
Cat5e supports up to 1Gbps, Cat6 supports 10Gbps over shorter distances, Cat6A supports 10Gbps up to 100 meters, while Cat8 supports up to 40Gbps for high-speed data center applications.
S/FTP cable uses an overall braided shield and individual foil shielding for each pair, providing excellent protection against electromagnetic interference (EMI) and crosstalk.
Yes. Our LAN cables are designed to support PoE, PoE+, and PoE++ systems, delivering both power and data transmission through a single cable.
Most Ethernet cables support transmission distances up to 100 meters under international cabling standards.
Yes. Certification availability depends on the specific product model and destination market requirements.
Yes. We offer OEM and ODM services including cable printing, customized packaging, labels and private branding.
Our engineering team can recommend the most suitable Ethernet cable based on bandwidth requirements, installation environment and project budget.
