| Ref. Standard | ANSI/TIA 568.2-D, ISO/IEC 11801, YD-T1019, UL444 |
|---|
| Typical Structure Parameters | ||||||
|---|---|---|---|---|---|---|
| Conductor Material | Conductor Diameter | Insulating Material | Insulator Diameter | Sheath Material | Outside Dia. | Color |
| Oxygen-Free Copper | 22AWG | Foamed-PE | 1.60±0.1 | PVC or LSZH | 8.30 mm | Optional |
| Mechanical and Electrical Performance | |
|---|---|
| Conductor Dc Resistance | 59.1 Ω/km |
| Dielectric Strength Between Conductors | 1.5KV ac for a minimum of 2s, without breakdown |
| Dc Resistance Unbalance Inside The Pairs | ≤4% |
| Mutual Capacitance | —— |
| Application Scenario | Description & Compliance |
|---|---|
| Extreme EMI & Industrial Shielding Zones | Specifically developed for high-frequency industrial automation, broadcasting equipment rooms, and environments facing hostile electromagnetic interference. The master-grade double shielding layout (Individual pair Al-Mylar foil + Total tinned copper braid) yields unmatched noise immunity. |
| Next-Gen 25G/40G Core Networks | The ultimate networking pipeline for AI computing clusters, hyper-scale cloud server farms, and high-speed storage area networks (SAN) requiring massive data transfers without bottleneck restrictions. |
| Short-Distance Backbone Switches | Perfectly optimized for top-performance switch-to-switch data center links and short-distance vertical backbone connections up to standard operational distances, keeping packet transport lossless. |
| Unprecedented 2GHz System Bandwidth | Delivers an incredible 2GHz (2000MHz) bandwidth channel capability, driving blindingly fast network application rates at 25Gbps and 40Gbps to easily outpace standard infrastructure limitations. |
| Flagship Category 8 Architecture | Built using heavy solid 22AWG pure Oxygen-Free Copper cores paired with low-loss Foamed-PE insulation. Reaches and fully exceeds the most rigorous Category 8 system benchmarks with an ultra-low resistance ($\le 59.1\ \Omega/\text{km}$). |
| Eco-Safety Public Infrastructure | Wrapped in optional high-grade PVC or flame-retardant LSZH (Low Smoke Zero Halogen) composite jackets, adhering strictly to smoke control and indoor building environmental codes. |
| International Cabling Certification | Meets and outperforms mainstream global data networking installation parameters, including strict ANSI/TIA 568.2-D, ISO/IEC 11801, YD-T1019, and UL444 industry certification criteria. |
| Instructions | |||
|---|---|---|---|
| Operating Temperature | -10~60°C | Construction Temperature | 0~40°C |
| Recommended Bending Radius for Laying | ≥8 * OD | Recommended to Lay Tension | ≤110N (Short-term) ≤20N (Long-term) |
| Packing | Optional, According to Customer Requirements to Discuss. |
|---|
